55-Standard COB led strip

Model COB led strips 384led/m 8mm 10W/m

( P/N: TB08-COB384W)

1. Completely seamless light, no led dot and hot spots.

2. Innovative design on circuit board for rough bending.

3. High efficiency of 100lm/W.

4. CRI>90, Natural color reproduction of illuminated objects.

5. Slight Voltage drop, High brightness consistency.

6. Extensive illumination thanks to a large beam angle of 180°.

7. 5 Years warranty.

Part No.	Color	Color Temperature/ Wave length	Voltage	Power	Lumen/m	CRI	Viewing Angle	LED QTY(/m)	LED Type	PCB width
TB08-COB384W	white	6500k	12/24 VDC	10W/m	1000lm	>90	180°	384 led	COB LED	8mm
TB08-COB384WW	WW	2700-3000k	12/24 VDC	10W/m	950lm	>90	180°	384 led	COB LED	8mm
TB08-COB384NW	NW	4000k	12/24 VDC	10W/m	1000lm	>90	180°	384 led	COB LED	8mm
TB08-COB384WW	WW	2400-2600k	12/24 VDC	10W/m	950lm	>90	180°	384 led	COB LED	8mm
TB08-COB384R	Red	625nm	12/24 VDC	10W/m		>90	180°	384 led	COB LED	8mm
TB08-COB384G	Green	535nm	12/24 VDC	10W/m		>90	180°	384 led	COB LED	8mm
TB08-COB384P	Pink	615nm	12/24 VDC	10W/m		>90	180°	384 led	COB LED	8mm
TB08-COB384B	Blue	460nm	12/24 VDC	10W/m		>90	180°	384 led	COB LED	8mm
TB08-COB384IB	Ice Blue	484nm	12/24 VDC	10W/m		>90	180°	384 led	COB LED	8mm
TB08-COB384Y	Yellow	2000-2200k	12/24 VDC	10W/m	850lm	>90	180°	384 led	COB LED	8mm
TB08-COB384O	Orange	1500-1700k	12/24 VDC	10W/m	850lm	>90	180°	384 led	COB LED	8mm

1. High quality residential lighting.

2. Cabinet lighting.
